Zebra VC8300 - Plate Bases for MT35 XX Mounts

Accessories and Mounting
125
Figure 91 Optional Mount Kits
Plate Bases for MT35XX Mounts
Plate bases are not recommended for forklift mounting solutions. If this requires a plate rather than a clamp
base, you must penetrate into the structure of the vehicle. This requires additional hardware. The following
plate bases are available:
• MT3501 - VESA Plate
• MT3502 - Circular Plate
Screw
Clamp Base
Lower Base
Nut
MT3505
Screw
Clamp Base
Lower Base
Nut
MT3507
Nut
Clamp Base
Lower Base
Screw
MT3509
Nut
Clamp Base
Lower Base
Screw
MT3510
