Zebra VC8300 User Manual

24
Installation
Introduction
This chapter provides instructions on installing the device.
Overview
The device can be installed in a variety of ways:
• Position the device horizontally on a desk or mounted on a vehicle console.
• Wall mount the device using the optional wall mount (see VC8300 Mounting Accessories on page
123).
• Overhead mount on a lift truck cage using mounting hardware.
Depending on the vibration resistance and pivoting demands, mounting brackets, clamp foots or RAM
mount elements can also be used to attach the device. Contact your Zebra sales office to find out more
about the range of available installation options.
WARNING: The unit could fall during transit or installation/mounting and cause injury. Always ensure that there
are two people available when installing or removing the device.
Mounting Instructions
Follow and retain the mounting instructions included with assembly kit when installing the device. See
Safety on page 17 for safety instructions.
Installing the Device
Electrical Installation
There are various electrical potentials when installing the unit on a vehicle such as a forklift.

Zebra VC8300 Specifications

General

Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Operating system version	8.1
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Speakers	Mono
RS-232 input ports	2
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Operating temperature (T-T)	-30 - 50 °C
Battery capacity	- mAh
Product color	Black
Keyboard layout	QWERTY
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	90 mm
Width	276 mm
Height	238 mm
Weight	3700 g
