Data Capture
101
Figure 76 RS6000 Bluetooth HID Barcode
2. Remove the battery from the RS507/RS507x/RS6000.
3. Re-install the battery into the RS507/RS507x/RS6000.
4. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
5. Swipe down from the status bar and then touch .
6. Touch Bluetooth.
7. The device begins searching for discoverable Bluetooth devices in the area and displays them under
AVAILABLE DEVICES.
8. Scroll through the list and select RS507/RS507x or RS6000.
The RS507/RS507x/RS6000 connects to the scanner and Connected appears below the device name.
The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is established.
Pairing a DS3678 Scanner
To connect an DS3678 scanner to the VC8300, use one of the following methods:
• Simple Serial Interface (SSI) mode
• Bluetooth Human Interface Device (HID) mode.
Pairing Using Simple Serial Interface
IMPORTANT: Make sure that DS3678 scanner has firmware version CAACKS00-003-R00D0.DAT or higher.
To pair the DS3678 scanner with the VC8300 using SSI:
1. Ensure that the scanner is in SSI mode.
2. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
3. On the VC8300, swipe up from the bottom of the Home screen and touch .
