Page #116 background image
Wireless
116
The Bluetooth radio in this device operates as a Class 2 device power class. The maximum output power is 2.5
mW and the expected range is 10 m (32.8 ft). A definition of ranges based on power class is difficult to obtain
due to power and device differences, and whether in open space or closed office space.
NOTE: It is not recommended to perform Bluetooth wireless technology inquiry when high rate 802.11b operation is required.
Security
The current Bluetooth specification defines security at the link level. Application-level security is not specified.
This allows application developers to define security mechanisms tailored to their specific need. Link-level
security occurs between devices, not users, while application-level security can be implemented on a per-user
basis. The Bluetooth specification defines security algorithms and procedures required to authenticate
devices, and if needed, encrypt the data flowing on the link between the devices. Device authentication is a
mandatory feature of Bluetooth while link encryption is optional.
Pairing of Bluetooth devices is accomplished by creating an initialization key used to authenticate the devices
and create a link key for them. Entering a common personal identification number (PIN) in the devices being
paired generates the initialization key. The PIN is never sent over the air. By default, the Bluetooth stack
responds with no key when a key is requested (it is up to user to respond to the key request event).
Authentication of Bluetooth devices is based-upon a challenge-response transaction. Bluetooth allows for a
PIN or passkey used to create other 128-bit keys used for security and encryption. The encryption key is
derived from the link key used to authenticate the pairing devices. Also worthy of note is the limited range and
fast frequency hopping of the Bluetooth radios that makes long-distance eavesdropping difficult.
Recommendations are:
Perform pairing in a secure environment
Keep PIN codes private and do not store the PIN codes in the device
Implement application-level security.
Bluetooth Profiles
The device supports the Bluetooth services listed in the table below:
Table 13 Bluetooth Profiles
Profile Description
Service Discovery Protocol
(SDP)
Handles the search for known and specific services as well as general
services.
Serial Port Profile (SPP) Allows use of RFCOMM protocol to emulate serial cable connection
between two Bluetooth peer devices. For example, connecting the
device to a printer.
Object Push Profile (OPP) Allows the device to push and pull objects to and from a push server.
Advanced Audio Distribution
Profile (A2DP)
Allows the device to stream stereo-quality audio to a wireless headset or
wireless stereo speakers.
Audio/Video Remote Control
Profile (AVRCP)
Allows the device to control A/V equipment to which a user has access.
It may be used in concert with A2DP.
Personal Area Network (PAN) Allows the use of Bluetooth Network Encapsulation Protocol to provide
L3 networking capabilities over a Bluetooth link. Only PANU role is
supported.

Table of Contents

Other manuals for Zebra VC8300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra VC8300 and is the answer not in the manual?

Zebra VC8300 Specifications

General IconGeneral
Display diagonal8 \
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Flash memory32 GB
Internal memory4 GB
Internal memory type-
Number of cores8
Processor model660
Processor familySnapdragon
Processor frequency2.2 GHz
Operating system version8.1
Operating system installedAndroid
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
SpeakersMono
RS-232 input ports2
Headphone connectivity3.5 mm
USB 2.0 ports quantity1
Operating temperature (T-T)-30 - 50 °C
Battery capacity- mAh
Product colorBlack
Keyboard layoutQWERTY
International Protection (IP) codeIP66
Harmonized System (HS) code84713000
Weight and Dimensions IconWeight and Dimensions
Depth90 mm
Width276 mm
Height238 mm
Weight3700 g
