Zebra VC8300 User Manual

Maintenance and Troubleshooting
216
Operation of the capacitive touch screen is recommended with:
• Clean, dry fingers.
• Clean, dry, soft gloves.
Troubleshooting
Table 17 Troubleshooting
Symptom Possible Cause Solution
The vehicle
computer does
not power on or
shuts off
suddenly.
The power cable ignition
sense wire (yellow) is
not connected properly.
Verify that the power cable is connected properly. See Wiring
Vehicle Power to the VC8300 on page 26.
Power cable not
connected properly or
unplugged.
Connect power cable to power cable portion underside of
vehicle computer. Turn the main power switch on.
If the vehicle computer
is powered by a vehicle
battery, the vehicle
battery is depleted.
Replace or charge the vehicle battery.
Cannot see
characters on
display.
Vehicle computer not
powered on (Power LED
is Off).
Press the Power button on.
Screen is too dark. Adjust the brightness; see Figure 1 on page 19.
The vehicle computer is
in suspend mode
(Power LED is on).
Press the Power button to turn on the vehicle computer.
The
touchscreen is
not working.
Replacement screen
protector was damaged.
Replace screen protector.
Touch screen is
damaged.
See system administrator.

Zebra VC8300 Specifications

General

Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Operating system version	8.1
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Speakers	Mono
RS-232 input ports	2
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Operating temperature (T-T)	-30 - 50 °C
Battery capacity	- mAh
Product color	Black
Keyboard layout	QWERTY
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	90 mm
Width	276 mm
Height	238 mm
Weight	3700 g
