Zebra VC8300 User Manual

Apps
71
Heater Control
IMPORTANT: Heater Control app is only applicable to freezer configurations.
The device heater ensures optimum performance in freezers. The heater benefits include:
• Touch screen heater clears condensation on the display.
• Port heater prevents condensation on contacts.
• UPS Battery requires a heater to operate below freezing temperatures.
• The user interface displays current temperatures.
Figure 47 Heater Control Screen
Temperatures
The Temperature tab displays the current temperature for the following:
• Serial Ports
• USB Ports
• Battery
• Keyboard
• Touch Panel (Freeze configurations only)
• Ambient.
Serial Port Heater
Use the Serial Ports Heater tab to enable and set the heater for the serial ports.
• Enable Heater - Turns on or off the serial port heater. When on, the switch turn red.
• Heater on threshold - Set the temperature at which the heater turns on (default - 5°C/41°F).
• Heater off threshold - Set the temperature at which the heater turns off (default - 15°C/59°F).

Zebra VC8300 Specifications

General

Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Operating system version	8.1
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Speakers	Mono
RS-232 input ports	2
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Operating temperature (T-T)	-30 - 50 °C
Battery capacity	- mAh
Product color	Black
Keyboard layout	QWERTY
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	90 mm
Width	276 mm
Height	238 mm
Weight	3700 g
