2N IP intercom User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 123/198
Sending mode – define whether it will be possible to send DTMF during a call by
pressing 0 through 9, * and # on the intercom numeric keypad. Set the sending
mode for incoming/outgoing/all calls.
In-Band (Audio) – enable classic DTMF dual tone sending in the audio band.
RTP (RFC-2833) – enable DTMF sending via the RTP according to RFC-2833.
SIP INFO (RFC-2976) – enable DTMF sending via SIP INFO messages according
to RFC-2976.
The tab below helps you define how DTMF characters shall be received from the
intercom. Check the DTMF receiving options and settings of the opponent to make the
function work properly.
In-Band (Audio) – enable classic DTMF dual tone receiving in the audio band.
RTP (RFC-2833) – enable DTMF receiving via the RTP according to RFC-2833.
SIP INFO (RFC-2976) – enable DTMF receiving via SIP INFO messages according
to RFC-2976.

2N IP intercom Specifications

General

Tamper Switch	Yes
Dimensions	Varies by model
Weight	Varies by model
Connectivity	Wi-Fi
Power Supply	12V DC
Operating Temperature	60°C
Protocols	SIP, ONVIF
Interfaces	Ethernet
Keypad	Optional
Card Reader	Optional
Display	Yes (selected models)
