2N IP intercom User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 166/198
5.4.11 SNMP
The integrate a remote intercom supervision functionality via the 2N IP intercoms
SNMP. The integrated SNMP agent becomes available when the Enhanced Integration
licence key is added. The intercoms support the SNMP version 2c.
List of Parameters
Community string – text string representing the access key to the MIB table
objects.
– IP address to which the SNMP traps are to be sent.Trap IP address
Note
Traps are not supported at the present version. operates 2N IP intercom
with request - response messages.
– download the current MIB definition from a device.Download MIB file

2N IP intercom Specifications

General

Tamper Switch	Yes
Dimensions	Varies by model
Weight	Varies by model
Connectivity	Wi-Fi
Power Supply	12V DC
Operating Temperature	60°C
Protocols	SIP, ONVIF
Interfaces	Ethernet
Keypad	Optional
Card Reader	Optional
Display	Yes (selected models)
