280 Chapter 8
Analysis and Processing of Result
Save and Recall the Agilent 4294A Internal Data
Contents of the data part when saving the data array
Table 8-9 is an example of the data part when specifying saving the data array.
Table 8-10 shows the contents of the saved data array.
Contents of the data part when saving the memory array
Table 8-11 is an example of the data part when specifying saving the memory array.
Table 8-9 Example of the data array data saved in the data part
(part of trace A)
"TRACE: A" Ü
"FORMAT: LOG" Ü
Ü
"Frequency"_"Data Real"_"Data Imag" Ü
4.00000000000e+01_1.976390e-02_5.641327e-03Ü
2.24493714300e+06_8.738007e+00_2.715469e+02Ü
4.48983428600e+06_2.407099e+01_5.634623e+02Ü
.............................................
Symbols in the table Ü : Linefeed, _ : Tab
Table 8-10 Contents of the trace data
Setup and data name Description
"TRACE: A" Type of trace
"FORMAT: LOG" Setup of display format
"Frequency" Measurement frequency points
"Data Real" Data array real part
"Data Imag" Data array imaginary part
Table 8-11 Example of the memory array data saved in the data
part (part of trace A)
"TRACE: A" Ü
"FORMAT: LOG" Ü
Ü
"Frequency"_"Memory Real"_"Memory Imag"Ü
4.00000000000e+01_1.976390e-02_5.641327e-03Ü
2.24493714300e+06_8.738007e+00_2.715469e+02Ü
4.48983428600e+06_2.407099e+01_5.634623e+02Ü
..........................................
Symbols in the table Ü : Linefeed, _ : Tab
