Chapter 8 281
Analysis and Processing of Result
Save and Recall the Agilent 4294A Internal Data
8. Analysis and Processing
of Result
Table 8-12 shows the contents of the saved memory array.
Contents of the data part when saving the data trace array
Table 8-13 is an example of the data part when specifying saving the data trace array.
Table 8-14 shows the contents of the saved data trace array.
Contents of the data part when saving the memory trace array
Table 8-12 Contents of the memory array
Setup and data array
name
Description
"TRACE: A" Type of trace
"FORMAT: LOG" Setup of display format
"Frequency" Measurement frequency points
"Memory Real" Memory array real part
"Memory Imag" Memory array imaginary part
Table 8-13 Example of the data trace array data saved in the data
part (part of trace A)
"TRACE: A" Ü
"FORMAT: LOG" Ü
Ü
"Frequency""Data Trace Real"_"Data Trace Imag"Ü
4.00000000000e+01_2.055326e-02_0.000000e+00Ü
2.24493714300e+06_2.716875e+02_0.000000e+00Ü
4.48983428600e+06_5.639762e+02_0.000000e+00Ü
..........
Symbols in the table Ü : Linefeed, _ : Tab
Table 8-14 Contents of the data trace array
Setup and data array
name
Description
"TRACE: A" Type of trace
"FORMAT: LOG" Setup of display format
"Frequency" Measurement frequency points
"Data Trace Real" Data trace array real part
"Data Trace Imag" Data trace array imaginary part
