370 Appendix B
Key Definitions
Softkeys displayed by pressing the [Display] key
HALF INSTR HALF
BASIC
|
Uses the upper half of the screen as the instrument screen
1
and the lower half as
the HP Instrument BASIC screen
2
.
DISA HIHB
ALL BASIC
|
Uses the entire screen as the HP Instrument BASIC screen
2
.
DISA ALLB
BASIC STATUS Allocates status lines (3 lines) for HP Instrument BASIC below the instrument
screen
1
.
DISA BASS
return Returns to Table B-14, “Display (Display) menu (2/2),” on page 366. (N/A)
1. The internal function of the 4294A can be divided into “instrument” and “HP Instrument BASIC” to control it. The instrument
screen means the screen used to display the information of “instrument.” It is used to display scales and traces of measurement
results, the list sweep table, the limit line table, and so on.
2. The internal function of the 4294A can be divided into “instrument” and “HP Instrument BASIC” to control it. The HP
Instrument BASIC screen means the screen used to display the information of HP Instrument BASIC. It is used to display
program lists, file lists, statuses, and so on.
Table B-22 Display color modification (Modify Color) menu
Key operation: [Display] - more 1/2 - MODIFY COLOR
Softkey Function GPIB command
INTENSITY Sets the intensity of information displayed on the screen (text, graphics) in a
percentage of the maximum value.
INTE <value>
BACKGROUND
INTENSITY
Sets the background intensity on the screen in a percentage of white balance. BACI <value>
MODIFY ITEM COLOR
ä
Displays Table B-23, “Item color modification (Color Item) menu (1/3),” on
page 370.
(N/A)
DEFAULT COLORS Returns all color configurations of items displayed on the screen to the factory
default states.
DEFC
return Returns to Table B-14, “Display (Display) menu (2/2),” on page 366. (N/A)
Table B-23 Item color modification (Color Item) menu (1/3)
Key operation: [Display] - more 1/2 - MODIFY COLOR - MODIFY ITEM COLOR
Softkey Function GPIB command
MODIFY COLOR ä Displays Table B-26, “Item color entry (Color Item) menu,” on page 372. (N/A)
TRC A DATA
|
Selects the trace A data trace as the display item that can be changed with the
MODIFY COLOR key.
COLO TRAD
TRC A MEM LIMIT
LINE
|
Selects the trace A memory trace, scale reference lines, and limit lines as the
display items that can be changed with the MODIFY COLOR key.
COLO TRAM
TRC B DATA
|
Selects the trace B data trace as the display item that can be changed with the
MODIFY COLOR key.
COLO TRBD
Table B-21 Display allocation (Disp Alloc) menu
Key operation: [Display] - more 1/2 - ALLOCATION
Softkey Function GPIB command
