Agilent Technologies 4294A User Manual

384 Appendix B
Key Definitions
Softkeys displayed by pressing the [Sweep] key
return Returns to Table B-43, “Sweep (Sweep) menu,” on page 383. (N/A)
Table B-45 Sweep time (Sweep Time) menu
Key operation: [Sweep] - TIME
Softkey Function GPIB command
SWEEP TIME Sets sweep time. SWET <value>
POINT DELAY Sets the measurement start delay time for each measurement point. PDELT <value>
SWEEP DELAY Sets the sweep start delay time for each sweep. SDELT <value>
return Returns to Table B-43, “Sweep (Sweep) menu,” on page 383. (N/A)
Table B-46 Sweep type (Sweep Type) menu
Key operation: [Sweep] - TYPE [ ]
Softkey Function GPIB command
LINEAR
|
Selects the linear sweep as the sweep type. The linear sweep linearly allocates
sweep points (measurement points) and performs sweeps within the sweep range
specified by start and stop (or center and span).
SWPT LIN
LOG
|
Selects the log (logarithmic) sweep as the sweep type. The log sweep
logarithmically allocates sweep points (measurement points) and performs
sweeps within the sweep range specified by start and stop (or center and span).
SWPT LOG
LIST Selects the list sweep as the sweep type. Before selecting the list sweep, you
must create a list sweep table with the EDIT LIST key in Table B-47, “List
sweep (List Sweep) menu,” on page 384.
SWPT LIST
return Returns to Table B-43, “Sweep (Sweep) menu,” on page 383. (N/A)
Table B-47 List sweep (List Sweep) menu
Key operation: [Sweep] - EDIT LIST
Softkey Function GPIB command
SEGMENT If there is a list sweep table, specify the segment number you want to edit. The
currently specified segment is indicated by the pointer (>) in the SEG column at
the leftmost area of the list sweep table.
SEGM <value>
EDIT ä Displays Table B-48, “Segment edit (Edit Segment) menu (1/3),” on page 385. SEDI
DELETE Executes the deletion of the segment specified by the pointer (>). SDEL
ADD ä Displays Table B-48, “Segment edit (Edit Segment) menu (1/3),” on page 385. SADD
Table B-44 Sweep parameter (Sweep Param) menu
Key operation: [Sweep] - PARAMETER [ ]
Softkey Function GPIB command
