414 Appendix B
Key Definitions
Softkeys displayed by pressing the [System] key
EXTERNAL TEST
|
Refer to “Service Manual.” (N/A)
DISPLAY TEST Refer to “Service Manual.” (N/A)
MAC ADDRESS Displays the MAC address assigned to this Agilent 4294A on the screen. A
unique MAC address is assigned to each instrument. The MAC address cannot
be changed.
(N/A)
FIRMWARE REVISION Displays the version information on the firmware currently installed in this
Agilent 4294A.
(N/A)
return Returns to Table B-74, “System (System) menu,” on page 404. (N/A)
Table B-93 System diagnosis (Diagnosis) menu
Key operation: [System] - DIAGNOSTIC TEST
Softkey Function GPIB command
