Alcatel OmniPCX Office Technical Documentation

File
1
INSTALLATION PROCEDURESPM5 : SYSTEM CONFIGURATION
Ed. 04 3/10Réf. 3EH 21000 BSAA
ISDN modem installation process (example)
This is for a FRITZ modem.
- Insert the modem installation CD-ROM
-Click the FRITZ !X PC Capi driver installer icon
- In the Wizard mode, indicate the serial port to connect the modem.
- At the end of the Wizard, reboot the PC
- Insert the modem installer CD-ROM
-Click the FRITZ !32 Communication Software installer icon
- In the Wizard mode, select Install and configure
- Use the default installation (click on Next in each Wizard screen)
- At the end of the Wizard mode, check the Install Capi-port driver box
- Select AVM ISDN1 Internet (PPP over ISDN)
- Reboot the PC.
RAS configuration process
-Open the Control panel.
-Open the Network folder.
- Select Services tab
-Click on Add.
- Select in the list Remote Access Services or, if not installed, add "remote access service" using pro-
cedure described in previous paragraph.
-Click on Properties.
- The list shows Com 1 Alizé Direct serial link connection
-Add FRITZ AWM ISDN1 Internet (PPP over ISDN. Important If another modem is all ready
installed on the port you decided to use, remove it and install the new one.
-Click on Continue
-Click on Close
- Reboot the PC
Alcatel OmniPCX Office remote access creation
-Open the My Computer Windows.
- Select the Dial up network icon.
- Create a new connection using default parameters and entering a connection name (xxx)
- Verify that the modem used is well AWM ISDN1 Internet (PPP over ISDN).
-Click on Next
- Do not enter any telephone number
-Click on Finish.
- Close the folder.

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
