6.2 Explanation of Windows
6-5
6
How to Operate Sampling Scope
Control Ch
Toggles the channel(s) to be controlled by Sampling, Auto Scale and Clear
Display.
All All channels
Single Active channel only
When Control Ch is set to Single, the buttons effective only for the active
channel are indicated by the same color as the active channel.
Figure 6.2.1-3 When Control Ch is Set to Single
Color of the active channel is displayed.
