Chapter 6 How to Operate Sampling Scope
6-22
Composite Histogram
Click Composite Histogram on the Graph selection buttons, TJ, RJ/PJ,
and DDJ histograms are displayed.
Figure 6.2.2.2-4 Composite Histogram
Table 6.2.2.2-4 Composite Histogram Item
Name Description
TJ Samples
RJ/PJ Samples
DDJ Samples
The number of samples for the histogram
