6.2 Explanation of Windows
6-23
6
How to Operate Sampling Scope
DDJ Histogram
Click DDJ Histogram on the Graph selection buttons, the histogram of
DDJ is displayed by edge.
Figure 6.2.2.2-5 DDJ Histogram
Table 6.2.2.2-5 DDJ Histogram Item
Name Description
All Edges When the button display is ON, the
histogram is displayed.
Rise Edges
Fall Edges
All Samples The number of samples for the both edges
histogram
Rise Samples The number of samples for the rising edge
histogram
Fall Samples The number of samples for the falling edge
histogram
