Chapter 6 How to Operate Sampling Scope
6-24
PJ vs Frequency
When clicking PJ vs Frequency on the Graph selection buttons, spectrum
of jitter is displayed.
Figure 6.2.2.2-6 PJ vs Frequency
Table 6.2.2.2-6 PJ vs Frequency Item
Name Description
PJ Calculate Calculates the jitter peak spectrum
frequency.
(PJ Frequency) Spectrum peak frequency
PJ Frequency
