Chapter 6 How to Operate Sampling Scope
6-40
Table 6.2.4-5 Settable Standards for PDJ measurement and Filter Sets (Unit Hz)
PDJ Filter
Standard HP0 HP1 HP1' HP2 HP' HP LP LP'
STM-0 10 100 – 20 k – 12 k 400 k –
STM-1 10 500 – 65 k – 12 k 1.3 M 500
STM-4 10 1 k – 250 k – 12 k 5 M 1 k
STM-16 10 5 k – 1 M – 12 k 20 M 5 k
STM-64 10 20 k 10 k 4 M 50 k 12 k 80 M 20 k
STM-256 – 80 k 20 k 16 M – – 320 M –
The jitter specification values specified in ITU-T G.825/Amd.1 Table 1 are
shown in the following table.
Table 6.2.4-6 Maximum permissible jitter at network interfaces
Interface
Measurement bandwidth,
–3dB frequencies (Hz)
Peak-to peak
amplitude (UIpp)
STM-1e 500 to 1.3 M 1.5
(Notes 1, 2) 65 k to 1.3 M 0.075
STM-1 500 to 1.3 M 1.5
(Note 3) 65 k to 1.3 M 0.15
STM-4 1 k to 5 M 1.5
(Note 3) 250 k to 5 M 0.15
STM-16 5 k to 20 M 1.5
(Note 3) 1 M to 20 M 0.15
STM-64 20 k to 80 M 1.5
(Note 3) 4 M to 80 M 0.15
STM-256 80 k to 320 M 1.5
(Note 3) 16 M to 320 M 0.18
NOTE 1 − Electrical format CMI-encoded, according to G.703.
NOTE 2 − For networks deployed with G.813 Option II clocks or G.812
Type II, III or IV clocks, STM-1 requirements apply to STM-1e.
NOTE 3 − STM-1 1 UI = 6.43 ns
STM-4 1 UI = 1.61 ns
STM-16 1 UI = 0.402 ns
STM-64 1 UI = 0.100 ns
STM-256 1 UI = 0.025 ns
