Chapter 2 Measurement
HA-8190V 2-46
Column replacement symbol
Usually, nothing is printed, but an “*” appears as in the example when it is time to replace the column.
HbA1c and HbF measurement results
Measurement results of standard solution obtained in calibration are shown as a value with one more decimal place
than that obtained in normal measurement.
The following indications are included in printouts if inaccurate measurement results were obtained.
Indication Description
--.- An abnormal measurement result was obtained. “****** Abnormal Fraction ******” will be printed, and
then below the chromatogram, a message about the abnormal value will be printed (see “5.4.
Abnormal Result Messages” on page 5-22).
PASS Measurement was not performed due to instructions from the external device.
REFERENCE:
Reagent information can be added to the end of the measurement result reports. See “3.7.2. Setting Up the
Printer” on page 3-26.
To Next Page
