2.5 Normal Measurement
HA-8190V 2-25
b On the [Main menu] screen, touch <4. View results>.
• The most recent measurement result will be displayed.
c Display the measurement results you want to view.
2 View the peak information.
a On the <View results> screen, touch the <Peak info.> tab.
• The retention time and area value for each peak will be listed.
3 View the chromatogram.
a On the <View results> screen, touch the <Chromato> tab.
• The chromatogram will appear.
Measurement result (Variant mode)
Button Description
Returns to the results of the previous sample.
Goes to the results of the next sample.
Returns to the [Main menu] screen.
Peak information (Variant mode)
Button Description
Returns to the results of the previous sample.
Goes to the results of the next sample.
Returns to the [Main menu] screen.
Chromatogram (Variant mode)
Button Description
Returns to the results of the previous sample.
Goes to the results of the next sample.
Returns to the [Main menu] screen.
To Next Page
