AUBO i5 - Page 75

©2015-2018 AUBO.All rights reserved.
Page 73
THE I SERIES STANDARD CONTROL BOX V4.3
Figure 8.30 Analog current output connect to current source
Analog output electrical specification
Parameter term
minimum value
Maximum value
Single VO terminal input voltage
0V
+10 V
Single CO terminal input current
0mA
20 mA
When connecting external devices, all external devices should be connected to the ground
with the control cabinet.
