User's Manual 148 Document #: LTRT-10466
Mediant 500L MSBR
Table 15-11: Static Route Table Parameter Descriptions
Parameter Description
Index
[StaticRouteTable_Index]
Defines an index number for the new table record.
The valid value is 0 to 29.
Note: Each table row must be configured with a unique index.
Device Name
CLI: device-name
[StaticRouteTable_DeviceName]
Assigns an IP network interface through which the static route's
Gateway is reached. The Device Name (or underlying device)
represents the IP network interface, including VLAN ID and
associated physical port(s).
The value must be identical to the value in the 'Underlying
Device' parameter of the required IP network interface in the
Interface table (see Configuring IP Network Interfaces on page
138).
For configuring Ethernet Devices, see Configuring Underlying
Ethernet Devices on page 137.
Destination
CLI: destination
[StaticRouteTable_Destination]
Defines the IP address of the destination host/network. The
destination can be a single host or a whole subnet, depending
on the prefix length configured for this routing rule.
Prefix Length
CLI: prefix-length
[StaticRouteTable_PrefixLength]
Defines the Classless Inter-Domain Routing (CIDR)-style
representation of a dotted-decimal subnet notation of the
destination host/network. The CIDR-style representation uses a
suffix indicating the number of bits that are set in the dotted-
decimal format. For example, the value 16 represents subnet
255.255.0.0. The value must be 0 to 31 for IPv4 interfaces and a
value of 0 to 64 for IPv6 interfaces.
The address of the host/network you want to reach is determined by an AND operation that is applied
to the fields 'Destination' and 'Prefix Length'. For example, to reach the network 10.8.x.x, enter
10.8.0.0 in the 'Destination' field and 16 in the 'Prefix Length'. As a result of the AND operation, the
value of the last two octets in the 'Destination' field is ignored. To reach a specific host, enter its IP
address in the 'Destination' field and 32 in the 'Prefix Length' field.
Gateway
CLI: gateway
[StaticRouteTable_Gateway]
Defines the IP address of the Gateway (next hop) used for traffic
destined to the subnet/host defined in the 'Destination' / 'Prefix
Length' field.
Notes:
The Gateway's address must be in the same subnet as the
IP address of the network interface that is associated with the
static route (using the 'Device Name' parameter -
The IP network interface associated
with the static route must
be of the same IP address family (IPv4 or IPv6).
Description
CLI: description
[StaticRouteTable_Description]
Defines an arbitrary name to easily identify the static route rule.
The valid value is a string of up to 20 characters.
