User's Manual 55. Reporting Information to External Party
Version 6.8 713 Mediant 500L MSBR
CDR Field Name Description Format
SIP Reason header, if exists, for
example: SIP ;cause=200 ;text="Call
completed elsewhere".
If no SIP Reason header exists, the
description is taken from the reason
text, if exists, of the SIP response
code, for example: "417 Unknown
Resource-Priority".
If no reason text exists in the SIP
response code, the description is
taken from an internal SIP response
mapping mechanism. For example, if
the device receives a SIP response
"422", it sends in the CDR "422
Session Interval Too Small method" as
the description.
Caller
Name of caller String of up to 36 characters
Callee
Name of called party String of up to 36 characters
Below shows an example of an SBC signaling CDR sent at the end of a call (call was
terminated normally):
[S=40] |SBCReportType |EPTyp |SIPCallId |SessionId |Orig |SourceIp
|SourcePort |DestIp |DestPort |TransportType |SrcURI
|SrcURIBeforeMap |DstURI |DstURIBeforeMap |Durat |TrmSd |TrmReason
|TrmReasonCategory |SetupTime |ConnectTime |ReleaseTime
|RedirectReason |RedirectURINum |RedirectURINumBeforeMap
|TxSigIPDiffServ|IPGroup (description) |SrdId (name)
|SIPInterfaceId |ProxySetId |IpProfileId (name) |MediaRealmId
(name) |DirectMedia |SIPTrmReason |SIPTermDesc |Caller |Callee
[S=41] |CALL_END |SBC |20767593291410201017029@10.33.45.80
|1871197419|LCL |10.33.45.80 |5060 |10.33.45.72 |5060 |UDP
|9001@10.8.8.10 |9001@10.8.8.10 |6001@10.33.45.80
|6001@10.33.45.80 |15 |LCL |GWAPP_NORMAL_CALL_CLEAR
|NORMAL_CALL_CLEAR |17:00:29.954 UTC Thu Oct 14 2014
|17:00:49.052 UTC Thu Oct 14 2014 |17:01:04.953 UTC Thu Oct 14
2014 |-1 | | |40 |1 |0 (SRD_GW) |1 |1 |1 () |0 (MR_1) |no |BYE
|Q.850 ;cause=16 ;text="loc |user 9928019 |
55.2.2.2 CDR Fields for SBC Media
The CDR fields for SBC media are listed in the table below. The media CDRs are
published for each active media stream, thereby allowing multiple media CDRs, where
each media CDR has a unique call ID corresponding to the signaling CDR.
Table 55-3: CDR Fields for SBC Media
CDR Field Name Description
MediaReportType
Report type (media start, update, or end)
SIPCallId
Unique call ID
Cid
Channel CID
MediaType
Media type (audio, video, or text)
