AudioCodes Mediant 500L MSBR

User's Manual 55. Reporting Information to External Party
Version 6.8 721 Mediant 500L MSBR
55.3 Configuring RADIUS Accounting
The device can send accounting data of SIP calls as call detail records (CDR) to a RADIUS
Accounting server. The device can send the accounting messages to the RADIUS server
upon call release, call connection and release, or call setup and release. For a list of the
CDR attributes, see the table following the procedure below.
 To configure RADIUS accounting:
1. Open the RADIUS Parameters page (Configuration tab > VoIP menu > SIP
Definitions > RADIUS Parameters Settings).
Figure 55-3: RADIUS Accounting Parameters Page
2. Set the 'Enable RADIUS Access Control' parameter to Enable.
3. Configure the remaining parameters as required. For a description of these
parameters, see ''RADIUS Parameters'' on page 1027.
4. Click Submit.
5. For your settings to take effect, reset the device with a flash burn.
The table below lists the RADIUS Accounting CDR attributes included in the
communication packets transmitted between the device and a RADIUS server.
Table 55-5: Supported RADIUS Accounting CDR Attributes
Attribute
Number
Attribute
Name
Vendor
Specific
Attribute
(VSA)
No.
Purpose
Value
Format
Example AAA
Request Attributes
1 user-name - Account number or
calling party number
or blank
String
up to 15
digits
long
5421385747 Start
Acc
Stop
Acc
4 nas-ip-
address
- IP address of the
requesting device
Numeric 192.168.14.43 Start
Acc
Stop
Acc
6 service-type - Type of service
requested
Numeric 1: login Start
Acc
Stop
Acc
26 h323-
incoming-
conf-id
1 SIP call identifier Up to
32
octets
- Start
Acc
Stop
Acc
