AudioCodes Mediant 500L MSBR

User's Manual 912 Document #: LTRT-10466
Mediant 500L MSBR
Parameter Description
the Alert-Info header is added to the value of the
FirstCallWaitingToneID parameter.
 Playing the call waiting tone according to PriorityIndex in the
ToneIndex table parameter.
 Playing the call waiting tone according to the parameter
“CallWaitingTone#' of a SIP INFO message.
The device plays the tone received in the 'play tone
CallWaitingTone#' parameter of an INFO message plus the value
of this parameter minus 1.
The valid range is -1 to 1,000. The default is -1 (i.e., not used).
Notes:
 This parameter is applicable only to analog interfaces.
 It is assumed that all Call Waiting Tones are defined in
sequence in the CPT file.
 SIP Alert-Info header examples:

Alert-Info:<Bellcore-dr2>

Alert-Info:<http://…/Bellcore-dr2> (where "dr2" defines call
waiting tone #2)
 The SIP INFO message is according to Broadsoft's application
server definition. Below is an example of such an INFO
message:
INFO sip:06@192.168.13.2:5060 SIP/2.0
Via:SIP/2.0/UDP
192.168.13.40:5060;branch=z9hG4bK040066422630
From:
<sip:4505656002@192.168.13.40:5060>;tag=1455352915
To: <sip:06@192.168.13.2:5060>
Call-ID:0010-0008@192.168.13.2
CSeq:342168303 INFO
Content-Length:28
Content-Type:application/broadsoft
play tone CallWaitingTone1
67.10.5.3 Call Forwarding Parameters
The call forwarding parameters are described in the table below.
Table 67-44: Call Forwarding Parameters
Parameter Description
Web: Enable Call
Forward
CLI: call-forward
[EnableForward]
Enables the Call Forwarding feature.
 [0] Disable
 [1] Enable (Default)
For FXS interfaces, the Call Forward table (FwdInfo parameter) must be
defined to use the Call Forward service. The device uses SIP REFER
messages for call forwarding.
Notes:
 To use this service, the devices at both ends must support this option.
 For the device to respond to SIP 3xx responses with a new SIP
request (forwarding the original request), set this parameter to
Enable.
