51.2 Viewing Ethernet Port Information
The Ethernet Port Information page displays read-only information about the Ethernet Port
connections.
 To view Ethernet port information:

Open the Ethernet Port Information page:
• Navigation menu tree: Status & Diagnostics tab > System Status menu >
Ethernet Port Info
• On the Home page, click any Ethernet port on the graphical display of the device
(see ''Viewing the Home Page'' on page 61)
Figure 51-2: Ethernet Port Information Page
Table 51-1: Ethernet Port Information Parameters
Parameter Description
Port Name Displays the name of the port.
Active Displays whether the port is active ("Yes") or not ("No").
Speed Displays the speed (in Mbps) of the Ethernet port.
Duplex Mode Displays whether the port is half- or full-duplex.
State Displays the state of the port:
 "Forwarding": Active port (data is being received and sent)
 "Disabled": Redundancy port
