30.4 Configuring Authentication
The Authentication table lets you configure an authentication username and password per
device FXS and FXO port.
Notes:
• For configuring whether authentication is done per port or for the entire device,
use the parameter AuthenticationMode.
• If authentication is configured for the entire device, the configuration in this table is
ignored.
• If the user name or password is not configured in this table, the port's phone
number (configured in the Trunk Group table) and global password (configured by
the global parameter, Password) are used instead for authentication of the port.
• After you click Submit, the password is displayed as an asterisk (*).
The following procedure describes how to configure authentication per port in the Web
interface. You can also configure this using the table ini file parameter, Authentication or
CLI command, configure voip > gw analoggw authentication.
 To configure authentication credentials per port:
1. Set the parameter 'Registration Mode' (AuthenticationMode) to Per Endpoint. This
can be configured in any of the following pages:
• Proxy & Registration page (see ''Configuring Proxy and Registration Parameters''
on page 309).
• Trunk Group Settings page (see ''Configuring Trunk Group Settings'' on page
375), where registration method is configured per Trunk Group.
2. Open the Authentication page (Configuration tab > VoIP menu > GW and IP to IP >
Analog Gateway > Authentication).
3. Click Add; the following dialog box appears:
Figure 30-4: Authentication Page - Edit Record
4. Configure authentication per port according to the parameters described in the table
below.
5. Click Submit, and then save ("burn") your settings to flash memory.
Table 30-1: Authentication Table Parameter Descriptions
Parameter Description
Index
[Authentication_Index]
(Read-only) Displays the index number of the table record.
Port (Read-only) Displays the port number.
