AudioCodes Mediant 500L MSBR

User's Manual 942 Document #: LTRT-10466
Mediant 500L MSBR
67.10.6.4 ISDN Parameters
The ISDN parameters are described in the table below.
Table 67-58: ISDN Parameters
Parameter Description
Web: ISDN Termination Side
EMS: Termination Side
CLI: isdn-termination-side
[TerminationSide]
Determines the ISDN termination side.
 [0] User side = (Default) ISDN User Termination Equipment
(TE) side.
 [1] Network side = ISDN Network Termination (NT) side.
Note: Select 'User side' when the PSTN or PBX side is configured
as 'Network side' and vice versa. If you don't know the device's
ISDN termination side, choose 'User side'. If the D-
channel alarm is
indicated, choose 'Network Side'.
The BRI module supports the ITU-T I.430 standard, which defines
the ISDN-BRI layer 1 specification. The BRI and PRI ports are
configured similarly, using this parameter. When an NT port is
active, it drives a 38-V line and sends an INFO1 signal (as defined
in ITU-T I.430 Table 4) on the data line to synchronize to a TE port
that might be connected to it. To stop the voltage and the INFO1
signal on the line, stop the trunk using the Stop Trunk button.
[TerminationSide_x]
Same as the description for parameter TerminationSide, but for a
specific trunk ID (where x denotes the Trunk ID and 0 is the first
Trunk).
Web: Enable ignoring ISDN
Disconnect with PI
CLI: ign-isdn-disc-w-pi
[KeepISDNCallOnDisconnect
WithPI]
Enables the device to ignore ISDN Disconnect messages with PI 1
or 8.
 [1] = The call (in connected state) is not released if a Q.931
Disconnect with PI (PI = 1 or 8) message is received during the
call.
 [0] = (Default) The call is disconnected.
Web: PI For Setup Message
CLI: pi-4-setup-msg
[PIForSetupMsg]
Determines whether and which Progress Indicator (PI) information
element (IE) is added to the sent ISDN Setup message. Some
ISDN protocols such as NI-2 or Euro ISDN can optionally contain
PI = 1 or PI = 3 in the Setup message.
 [0] = PI is not added (default).
 [1] = PI 1 is added to a sent ISDN Setup message - call is not
end-to-end ISDN.
 [3] = PI 3 is added to a sent ISDN Setup message - calling
equipment is not ISDN.
Web/EMS: B-channel
Negotiation
CLI: b-ch-negotiation
[BchannelNegotiation]
Defines the ISDN B-channel negotiation mode.
 [0] Preferred
 [1] Exclusive (default)
 [2] Any
Notes:
 For some ISDN variants, when 'Any' (2) is selected, the Setup
message excludes the Channel Identification IE.
 The Any' (2) option is applicable only if the following conditions
are met:

The parameter TerminationSide is set to 0 ('User side').

The PSTN protocol type (ProtocolType) is configured as
Euro ISDN.
