User's Manual 18. Services
Version 6.8 209 Mediant 500L MSBR
Parameter Description
Web: SIP server type
CLI: sip-server-type
[DhcpServer_SipServerType]
Defines the type of SIP server address. The actual
defined in the 'SIP server' parameter (see above). Encoding
is done per SIP Server Type, as defined in RFC 3361.
[0] DNS names = (Default) The 'SIP server' parameter is
configured with an FQDN of the SIP server.
[1] IP address = The 'SIP server' parameter configured
with an IP address of the SIP server.
18.1.2 Configuring the Vendor Class Identifier
The DHCP Vendor Class table lets you configure up to 10 Vendor Class Identifier (VCI)
names (DHCP Option 60). When the table is configured, the device's DHCP server
responds only to DHCPDiscover requests that contain Option 60 and that match one of the
DHCP VCIs configured in the table. If you have not configured any entries in the table, the
DHCP server responds to all DHCPDiscover requests, regardless of the VCI.
The VCI is a string that identifies the vendor and functionality of a DHCP client to the
DHCP server. For example, Option 60 can show the unique type of hardware (e.g.,
"AudioCodes 440HD IP Phone") or firmware of the DHCP client. The DHCP server can
then differentiate between DHCP clients and process their requests accordingly.
The following procedure describes how to configure the DHCP VCIs in the Web interface.
You can also configure this using the table ini file parameter, DhcpVendorClass or CLI
command, configure voip > dhcp vendor-class.
To configure DHCP Vendor Class Identifiers:
1. Open the DHCP Servers page (Configuration tab > VoIP menu > Services > DHCP
Severs).
2. In the DHCP Servers table, select the row of the desired DHCP server for which you
want to configure VCIs, and then click the DHCP Vendor Class Table link located at
the bottom of the page; the DHCP Vendor Class Table page opens.
3. Click Add; the following dialog box appears:
4. Configure a VCI for the DHCP server according to the parameters described in the
table below.
5. Click Submit.
Table 18-3: DHCP Vendor Class Table Parameter Descriptions
Parameter Description
Web: Index
CLI: dhcp vendor-class <index>
[DhcpVendorClass_Index]
Defines an index number for the new table record.
Note: Each table row must be configured with a unique
index.
Web: DHCP Server Index
CLI: dhcp-server-number
[DhcpVendorClass_DhcpServerIndex]
Associates the VCI table entry with a DHCP server that
you configured in ''Configuring the DHCP Server'' on page
205.
Note: Currently, only one DHCP server (Index 0) can be
configured and therefore, this parameter is always set at 0.
Web: Vendor Class Identifier
CLI: vendor-class
[DhcpVendorClass_VendorClassId]
Defines the value of the VCI DHCP Option 60.
The valid value is a string of up to 80 characters. By
default, no value is defined.
