54.12 Viewing IP Connectivity
The IP Connectivity page displays on-line, read-only network diagnostic connectivity
information on all destination IP addresses configured in the Outbound IP Routing table
(see ''Configuring Outbound IP Routing'' on page 405).
Note: he information in columns 'Quality Status' and 'Quality Info' (per IP address) is
reset if two minutes elapse without a call to that destination.
 To view IP connectivity information:
1. In the Routing General Parameters page, set the 'Enable Alt Routing Tel to IP'
parameter (AltRoutingTel2IPMode) to Enable or Status Only (see ''Configuring
General Routing Parameters'' on page 405).
2. Open the IP Connectivity page (Status & Diagnostics tab > VoIP Status menu > IP
Connectivity).
Figure 54-11: IP Connectivity Page
Table 54-6: IP Connectivity Parameters
Column Name Description
IP Address
The IP address can be one of the following:
 IP address defined as the destination IP address in the Outbound IP
Routing table.
 IP address resolved from the host name defined as the destination IP
address in the Outbound IP Routing table.
Host Name
Host name (or IP address) as configured in the Outbound IP Routing table.
Connectivity
Method
The method according to which the destination IP address is queried
periodically (SIP OPTIONS request).
