67.10.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 67-40: Digit Collection and Dial Plan Parameters
Parameter Description
Web/EMS: Dial Plan Index
CLI: dial-plan-index
[DialPlanIndex]
Defines the Dial Plan index to use in the external Dial Plan file. The
Dial Plan file is loaded to the device as a .dat file (converted using
the DConvert utility). The Dial Plan index can be defined globally or
per Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1 denotes
PLAN2, and so on. The default is -
1, indicating that no Dial Plan file
is used.
Notes:
 If this parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If this parameter is configured to select a Dial Plan index from
an external Dial Plan file, the device first attempts to locate a
matching digit pattern in the Dial Plan file, and if not found, then
attempts to locate a matching digit pattern in the Digit Map rules
configured by the DigitMapping parameter.
 This parameter is applicable also to ISDN with overlap dialing.
 This parameter can also be configured in a Tel Profile.
 For more information on the Dial Plan file, see ''Dialing Plans for
Digit Collection'' on page 622.
CLI: tel2ip-src-nb-map-dial-
index
[Tel2IPSourceNumberMappin
gDialPlanIndex]
Defines the Dial Plan index in the external Dial Plan file for the Tel-
to-IP Source Number Mapping feature.
The valid value range is 0 to 7, defining the Dial Plan index [Plan x]
in the Dial Plan file. The default is -1 (disabled).
For more information on this feature, see ''Modifying ISDN-to-IP
Calling Party Number'' on page 629.
Web: Digit Mapping Rules
EMS: Digit Map Pat terns
CLI: default-dm
[DigitMapping]
Defines the digit map pattern (used to reduce the dialing period
when ISDN overlap dialing for digital interfaces). If the digit string
(i.e., dialed number) matches one of the patterns in the digit map,
the device stops collecting digits and establishes a call with the
collected number.
The digit map pattern can contain up to 52 options (rules), each
separated by a vertical bar (|). The maximum length of the entire
digit pattern is 152 characters. The available notations include the
following:
 [n-m]: Range of numbers (not letters).
 . (single dot): Repeat digits until next notation (e.g., T).
 x: Any single digit.
 T: Dial timeout (configured by the TimeBetweenDigits
parameter).
 S: Short timer (configured by the TimeBetweenDigits para
meter;
default is two seconds) that can be used when a specific rule is
defined after a more general rule. For example, if the digit map
is 99|998, then the digit collection is terminated after the first two
9 digits are received. Therefore, the second rule of 998 can
never be matched. But when the digit map is 99s|998, then after
dialing the first two 9 digits, the device waits another two
