User's Manual 218 Document #: LTRT-10466
Mediant 500L MSBR
3. Configure a SIP recording route according to the parameters described in the table
below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 18-6: SIP Recording Routing Parameter Descriptions
Parameter Description
Index
[SIPRecRouting_Index]
Defines an index number for the new table record.
Recorded IP Group ID
CLI: recorded-ip-group-id
[SIPRecRouting_RecordedIPGroupI
D]
Defines the IP Group participating in the call and the
recording is done on the leg interfacing with this IP Group.
Note: For an SBC RTP-SRTP session, the recorded IP
Group must be set to the RTP leg if recording is required to
be RTP, or set to the SRTP leg if recording is required to be
SRTP.
Recorded Source Prefix
CLI: recorded-src-prefix
[SIPRecRouting_RecordedSourceP
refix]
Defines calls to record based on source number or URI.
Recorded Destination Prefix
CLI: recorded-dst-prefix
[SIPRecRouting_RecordedDestinati
onPrefix]
Defines calls to record based on destination number or URI.
Peer IP Group ID
CLI: peer-ip-group-id
[SIPRecRouting_PeerIPGroupID]
Defines the peer IP Group that is participating in the call.
Caller
CLI: caller
[SIPRecRouting_Caller]
Defines which calls to record according to which party is the
caller.
[0] Both (default) = Caller can be peer or recorded side
[1] Recorded Party
Peer Party
Recording Server (SRS) IP Group ID
CLI: srs-ip-group-id
[SIPRecRouting_SRSIPGroupID]
Defines the IP Group of the recording server (SRS).
Note: The SIP Interface used for communicating with the
SRS is according to the SRD assigned to the SRS IP Group
(in the IP Group table). If two SIP Interfaces are associated
with the SRD - one for "SBC" and one for "GW &IP2IP" – the
device uses the "SBC" SIP Interface. If no SBC SIP Interface
type is configured, the device uses the “GW & IP2IP”
interface.
