User's Manual 18. Services
Version 6.8 257 Mediant 500L MSBR
Rule's condition is not met: The device runs the next rule in the Set ID. When the
device reaches the end of the Set ID and no Exit was performed, the Set ID ends with
a "True" result.
Note: If the source and/or destination numbers are manipulated by the Call Setup
rules, they revert to their original values if the device moves to the next routing rule.
The following procedure describes how to configure Call Setup Rules in the Web interface.
You can also configure Call Setup Rules using the table ini file parameter, CallSetupRules
or CLI command, configure voip/services call-setup-rules.
To configure a Call Setup rule:
1. Open the Call Setup Rules table (Configuration tab > VoIP menu > Services > Call
Setup Rules).
2. Click Add; the following dialog box appears:
Figure 18-27: Call Setup Rules Table - Add Record
3. Configure a Call Setup rule according to the parameters described in the table below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 18-17: Call Setup Rules Parameter Descriptions
Parameter Description
Index
[CallSetupRules_Index]
Defines an index number for the new table record.
Note: Each rule must be configured with a unique index.
Rules Set ID
CLI: rules-set-id
[CallSetupRules_RulesSetID]
Defines a Set ID for the rule. You can define the same Set
ID for multiple rules to create a group of rules. You can
configure up to 10 Set IDs, where each Set ID can include
up to 10 rules. The Set ID is used to assign the Call Setup
rules to a routing rule in the routing table.
The valid value is 0 to 9. The default is 0.
