3. Click Add; the following dialog box appears:
Figure 20-3: Remote Media Subnet - Add Record
4. Configure the Remote Media Subnet according to the parameters described in the
table below.
5. Click Submit, and then save ("burn") your settings to flash memory.
Table 20-2: Remote Media Subnet Table Parameter Descriptions
Parameter Description
Index
[RemoteMediaSubnet_RemoteMediaSubnetIndex]
Defines an index number for the new table
record.
Sub-Realm Name
CLI: name
[RemoteMediaSubnet_RemoteMediaSubnetName]
Defines an arbitrary name to easily identify
the Remote Media Subnet.
The valid value is a string of up to 20
characters.
Prefix Length
CLI: prefix-length
[RemoteMediaSubnet_PrefixLength]
Defines the subnet mask in Classless Inter-
Domain Routing (CIDR) notation. For
example, 16 denotes 255.255.0.0.
The default is 16.
Address Family
CLI: address-family
[RemoteMediaSubnet_AddressFamily]
Defines the IP address protocol.
 [2] IPv4 Manual (default)
 [10] IPv6 Manual
Destination IP
CLI: dst-ip-address
[RemoteMediaSubnet_DstIPAddress]
Defines the IP address of the destination.
The default is 0.0.0.0.
QOE Profile Name
CLI: qoe-profile
[RemoteMediaSubnet_QOEProfileName]
Assigns a Quality of Experience Profile to the
Remote Media Subnet.
BW Profile Name
CLI: bw-profile
[RemoteMediaSubnet_BWProfileName]
Assigns a Bandwidth Profile to the Remote
Media Subnet.
