User's Manual 546 Document #: LTRT-10466
Mediant 500L MSBR
The device resolves this by replacing the call identifiers received from the application
server with the correct call identifiers (e.g., user A and user B). Thus, users subscribed to
the service can receive relevant NOTIFY messages from the device and use the service.
Figure 33-2: Interworking NOTIFY XML Body for Application Server
To enable this feature, set the 'SBC Dialog-Info Interworking'
(EnableSBCDialogInfoInterworking) parameter to Enable. When this feature is disabled,
the device forwards the NOTIFY message as is, without modifying its XML body.
Below is an example of an XML body where the call-id, tags, and URIs have been
replaced by the device:
<?xml version="1.0"?>
<dialog-info xmlns="urn:ietf:params:xml:ns:dialog-info"
version="10" state="partial"
entity="sip:alice@example.com">
<dialog id="zxcvbnm3" call-id="67402270@10.132.10.150"
local-tag="1c137249965"
remote-tag="CCDORRTDRKIKWFVBRWYM" direction="initiator">
<state event="replaced">terminated</state>
</dialog>
<dialog id="sfhjsjk12" call-id="67402270@10.132.10.150"
local-tag="1c137249965"
remote-tag="CCDORRTDRKIKWFVBRWYM" direction="receiver">
<state reason="replaced">confirmed</state>
<replaces
call-id="67402270@10.132.10.150"
local-tag="1c137249965"
remote-tag="CCDORRTDRKIKWFVBRWYM"/>
<referred-by>
sip:bob-is-not-here@vm.example.net
</referred-by>
<local>
<identity display="Jason Forster">
sip:jforsters@home.net
</identity>
<target uri="sip:alice@pc33.example.com">
<param pname="+sip.rendering" pval="yes"/>
</target>
</local>
<remote>
<identity display="Cathy Jones">
sip:cjones@example.net
</identity>
<target uri="sip:line3@host3.example.net">
