User's Manual 708 Document #: LTRT-10466
Mediant 500L MSBR
JitterBuffer: JBA=3 JBR=0 JBN=7 JBM=10 JBX=300
PacketLoss: NLR=0.00 JDR=0.00
BurstGapLoss: BLD=0.00 BD=0 GLD=0.00 GD=6325 GMIN=16
Delay: RTD=0 ESD=11
Signal: SL=-34 NL=-67 RERL=17
QualityEst: RLQ=93 MOSLQ=4.1
MOSCQ=4.10
RemoteMetrics:
Timestamps: START=2015-12-16T20:09:45Z STOP=2015-12-16T20:09:52Z
JitterBuffer: JBA=3 JBR=0 JBN=0 JBM=0 JBX=300
PacketLoss: NLR=0.00 JDR=0.00
BurstGapLoss: BLD=0.00 BD=0 GLD=0.00 GD=0 GMIN=16
Delay: RTD=65535 ESD=0
QualityEst:
DialogID: 20328634741612201520943@172.17.116.201;to-
tag=1c1690611502;from-tag=1c2032864069To configure RTCP XR:
1. Open the RTP/RTCP Settings page (Configuration tab > VoIP menu > Media >
RTP/RTCP Settings). The RTCP XR parameters are listed under the RTCP XR
Settings group:
Figure 55-1: RTCP XR Parameters in RTP/RTCP Settings Page
2. Under the RTCP XR Settings group, configure the following:
• 'Enable RTCP XR' (VQMonEnable) - enables voice quality monitoring and RTCP
XR.
• 'Burst Threshold' (VQMonBurstHR) - defines the voice quality monitoring
excessive burst alert threshold.
• 'Delay Threshold' (VQMonDelayTHR) - defines the voice quality monitoring
excessive delay alert threshold.
• 'R-Value Delay Threshold' (VQMonEOCRValTHR) - defines the voice quality
monitoring end of call low quality alert threshold.
• 'Minimum Gap Size' (VQMonGMin) - defines the voice quality monitoring
minimum gap size (number of frames).
• 'RTCP XR Packet Interval' (RTCPInterval) - defines the time interval between
adjacent RTCP reports.
• 'Disable RTCP XR Interval Randomization' (DisableRTCPRandomize) -
determines whether RTCP report intervals are randomized or whether each
report interval accords exactly to the parameter RTCPInterval.
