User's Manual 55. Reporting Information to External Party
Version 6.8 717 Mediant 500L MSBR
Field Name Description
Amount
0-999999
Data is stored per call and sent in the syslog as follows:
currency-type: amount multiplier for currency charge (euro or usd)
recorded-units: for unit charge (1-999999)
Mult
0,001-1000 (in steps of 10)
(See explanation above.)
TrmReasonCategory
Termination reason category:
Calls with duration 0 (i.e., not connected):
NO_ANSWER - GWAPP_NORMAL_CALL_CLEAR,
GWAPP_NO_USER_RESPONDING,
GWAPP_NO_ANSWER_FROM_USER_ALERTED
BUSY - GWAPP_USER_BUSY
NO_RESOURCES -
GWAPP_RESOUUCE_UNAVAILABLE_UNSPECIFIED,
RELEASE_BECAUSE_NO_CONFERENCE_RESOURCES_LEFT
,
RESOURCE_BECAUSE_NO_TRANSCODING_RESOURCES_L
EFT, RELEASE_BECAUSE_GW_LOCKED
NO_MATCH -
RELEASE_BECAUSE_UNMATCHED_CAPABILITIES
FORWARDED - RELEASE_BECAUSE_FORWARD
GENERAL_FAILED - any other reason
Calls with duration:
NORMAL_CALL_CLEAR - GWAPP_NORMAL_CALL_CLEAR
ABNORMALLY_TERMINATED - Anything else
Reasons not belonging to above categories
RedirectNumBeforeMap
Redirect number before manipulation
SrdId
SRD ID name
SIPInterfaceId
SIP interface ID
ProxySetId
Proxy Set ID
IpProfileId
IP Profile ID name
MediaRealmId
Media Realm name
SigTransportType
SIP signaling transport type (UDP, TCP, or TLS)
TxRTPIPDiffServ
Media IP DiffServ
TxSigIPDiffServ
Signaling IP DiffServ
LocalRFactor
Local R-factor
Note: If the RTCP XR feature is unavailable (not licensed or disabled),
this R-factor VoIP metric is not provided. Instead, the device sends the
CDR field with the value 127, meaning that information is unavailable.
RemoteRFactor
Remote R-factor
Note: If the RTCP XR feature is unavailable (not licensed or disabled),
this R-factor VoIP metric is not provided. Instead, the device sends the
CDR field with the value 127, meaning that information is unavailable.
LocalMosCQ
Local MOS for conversation quality
RemoteMosCQ
Remote MOS for conversation quality
