User's Manual 67. Configuration Parameters Reference
Version 6.8 855 Mediant 500L MSBR
Parameter Description
From: sip:A@domain.com;tag=99asd
To: sip:C@domain.com
Refer-To: (URI that identifies B's UA)
The Refer-To header needs to contain a URI that user C can use to
place a call to user B. This call needs to route to the specific UA
instance that user B is using to talk to user A. User B should provide
user A with a URI that has to be usable by anyone. It needs to be a
GRUU.
Obtaining a GRUU: The mechanism for obtaining a GRUU is
through registrations. A UA can obtain a GRUU by generating a
REGISTER request containing a Supported header field with the
value “gruu”. The UA includes a “+sip.instance” Contact header
parameter of each contact for which the GRUU is desired. This
Contact parameter contains a globally unique ID that identifies
the UA instance. The global unique ID is created from one of the
following:
If the REGISTER is per the device’s client (endpoint), it is the
MAC address concatenated with the phone number of the
client.
If the REGISTER is per device, it is the MAC address only.
When using TP, “User Info” can be used for registering per
endpoint. Thus, each endpoint can get a unique id – its
phone number. The globally unique ID in TP is the MAC
address concatenated with the phone number of the
endpoint.
If the remote server doesn’t support GRUU, it ignores the
parameters of the GRUU. Otherwise, if the remote side also supports
GRUU, the REGISTER responses contain the “gruu” parameter in
each Contact header. This parameter contains a SIP or SIPS URI
that represents a GRUU corresponding to the UA instance that
registered the contact. The server provides the same GRUU for the
same AOR and instance-id when sending REGISTER again after
registration expiration. RFC 5627 specifies that the remote target is a
GRUU target if its’ Contact URL has the "gr" parameter with or
without a value.
Using GRUU: The UA can place the GRUU in any header field
that can contain a URI. It must use the GRUU in the following
messages: INVITE request, its 2xx response, SUBSCRIBE
request, its 2xx response, NOTIFY request, REFER request and
its 2xx response.
EMS: Is CISCO Sce Mode
[IsCiscoSCEMode]
Determines whether a Cisco gateway exists at the remote side.
[0] = (Default) No Cisco gateway exists at the remote side.
[1] = A Cisco gateway exists at the remote side.
When a Cisco gateway exists at the remote side, the device must set
the value of the 'annexb' parameter of the fmtp attribute in the SDP
to 'no'. This logic is used if the parameter
EnableSilenceCompression is set to 2 (enable without adaptation). In
this case, Silence Suppression is used on the channel but not
declared in the SDP.
Note: The IsCiscoSCEMode parameter is applicable only when the
selected coder is G.729.
Web: User-Agent Information
EMS: User Agent Display Info
Defines the string that is used in the SIP User-Agent and Server
response headers. When configured, the string
<UserAgentDisplayInfo value>/software version' is used, for
