User's Manual 67. Configuration Parameters Reference
Version 6.8 885 Mediant 500L MSBR
Parameter Description
[1] Enable = No Randomize
EMS: RTCP XR Collection Server
Transport Type
CLI: rtcpxr-collect-serv-transport
[RTCPXRESCTransportType]
Defines the transport layer used for outgoing SIP dialogs
initiated by the device to the RTCP XR Collection Server.
[-1] Not Configured (default)
[0] UDP
[1] TCP
[2] TLS
Notes:
When set to [-1], the value of the SIPTransportType
parameter is used.
This parameter is applicable only to the Gateway
application.
Web: RTCP XR Collection Server
EMS: Esc IP
CLI: rtcp-xr-coll-srvr
[RTCPXREscIP]
Defines the IP address of the Event State Compositor (ESC).
The device sends RTCP XR reports to this server, using SIP
PUBLISH messages, according to Internet-Draft draft-ietf-
sipping-rtcp-summary-13. The address can be configured as a
numerical IP address or as a domain name.
Note: This parameter is applicable only to the Gateway
application.
Web: Gateway RTCP XR Report
Mode
EMS: Report Mode
CLI: rtcp-xr-rep-mode
[RTCPXRReportMode]
Enables the device to send RTCP XR in SIP PUBLISH
messages to the Event State Compositor (ESC) server and
defines the interval at which they are sent.
[0] Disable = (Default) RTCP XR is not sent.
[1] End Call = RTCP XR is sent at the end of the call.
[2] End Call & Periodic = RTCP XR is sent at the end of the
call and periodically according to the RTCPInterval
parameter.
[3] End Call & End Segment = RTCP XR is sent at the end of
the call and at the end of each media segment of the call. A
media segment is a change in media, for example, when the
coder is changed or when the caller toggles between two
called parties (using call hold/retrieve). The RTCP XR sent at
the end of a media segment contains information only of that
segment. If the segment does not contain RTP/RTCP content,
the RTCP XR is not sent. For call hold, the device sends an
RTCP XR each time the call is placed on hold and each time it
is retrieved. In addition, the Start timestamp in the RTCP XR
indicates the start of the media segment; the End timestamp
indicates the time of the last sent periodic RTCP XR (typically,
up to 5 seconds before reported segment ends).Note: This
parameter is applicable only to the Gateway application.
Web: SBC RTCP XR Report Mode
CLI: sbc-rtcpxr-report-mode
[SBCRtcpXrReportMode]
Enables the sending of RTCP XR reports of QoE metrics at
the end of each call session (i.e., after a SIP BYE). The RTCP
XR is sent in the SIP PUBLISH message.
[0] Disable (default)
[1] End of Call
Note: This parameter is applicable only to the SBC
application.
