AudioCodes Mediant 500L MSBR

User's Manual 67. Configuration Parameters Reference
Version 6.8 977 Mediant 500L MSBR
Parameter Description
Services for Euro ISDN on page 479).
Web: Analog Metering
Type
EMS: Metering Type
CLI: metering-type
[MeteringType]
Determines the metering method for generating pulses (sinusoidal
metering burst frequency) by the FXS port.
 [0] 12 KHz = (Default) 12 kHz sinusoidal bursts.
 [1] 16 KHz = 16 kHz sinusoidal bursts.
 [2] = Polarity Reversal pulses.
Notes:
 For this parameter to take effect, a device reset is required.
 This parameter is applicable only to FXS interfaces.
Web: Analog TTX Voltage
Level
EMS: TTX Voltage Level
[AnalogTTXVoltageLevel ]
Determines the metering signal/pulse voltage level (TTX).
 [0] 0V = 0 Vrms sinusoidal bursts.
 [1] 0.5V = (Default) 0.5 Vrms sinusoidal bursts.
 [2] 1V = 1 Vrms sinusoidal bursts
Notes:
 For this parameter to take effect, a device reset is required.
 This parameter is applicable only to FXS interfaces.
Charge Codes Table
Web: Charge Codes Table
EMS: Charge Codes
CLI: configure voip > gw
analoggw ChargeCode
[ChargeCode]
This table parameter configures metering tones and their time intervals
that the FXS interface generates to the Tel side or the Euro ISDN trunk
sends in AOC Facility messages to the PSTN (i.e., PBX).
The format of the ini file table parameter is as follows:
[ChargeCode]
FORMAT ChargeCode_Index = ChargeCode_EndTime1,
ChargeCode_PulseInterval1, ChargeCode_PulsesOnAnswer1,
ChargeCode_EndTime2, ChargeCode_PulseInterval2,
ChargeCode_PulsesOnAnswer2, ChargeCode_EndTime3,
ChargeCode_PulseInterval3, ChargeCode_PulsesOnAnswer3,
ChargeCode_EndTime4, ChargeCode_PulseInterval4,
ChargeCode_PulsesOnAnswer4;
[\ChargeCode]
Where,
 EndTime = Period (1 - 4) end time.
 PulseInterval = Period (1 - 4) pulse interval.
 PulsesOnAnswer = Period (1 - 4) pulses on answer.
For example:
ChargeCode 1 = 7,30,1,14,20,2,20,15,1,0,60,1;
ChargeCode 2 = 5,60,1,14,20,1,0,60,1;
ChargeCode 3 = 0,60,1;
ChargeCode 0 = 6, 3, 1, 12, 2, 1, 18, 5, 2, 0, 2, 1;
Notes:
 To associate a configured Charge Code to an outgoing Tel-to-
IP call,
use the Outbound IP Routing table.
 To configure the Charge Codes table using the Web interface, see
Configuring Charge Codes Table on page 481.
