Fields in the Basic Parameters menu.
Field Description
Group Description Enter a unique name for the Drop In group.
Mode Select which mode is to be used to send the MAC addresses of
network components.
Possible values:
• *+ (default value): ARP packets and IP packets
belonging to the drop-in network are routed transparently
(unchanged).
• ?(: ARP packets and IP packets related to the drop-in
network are forwarded with the MAC address of the corres-
ponding interface.
Exclude from NAT
(DMZ)
Here you can take data traffic from NAT.
Use this function to, for example, ensure that certain web serv-
ers in a DMZ can be accessed.
The function is enabled with "1.
The function is disabled by default.
Network Configuration Select how an IP address / netmask is assigned to the Drop In
network.
Possible values:
• % (default value)
• 5@6
Network Address Only for Network Configuration = %
Enter the network address of the Drop In network.
Netmask Only for Network Configuration = %
Enter the corresponding netmask.
Local IP Address Only for Network Configuration = %
Enter the local IP address. This IP address must be identical for
all the Ethernet ports in a network.
10 Networking bintec elmeg GmbH
284 bintec RS Series
