SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 3
31-10
11. Place assembly hub down on workbench,
remove bolts.
12. With your fingers, remove the overrunning clutch
plug.
86065269
20
13. Lift housing off of the hub.
86065269
21
14. Remove the keys, 1, and spring, 2, from the hub.
86065269
1
2
22
