SECTION 31 - IMPLEMENT POWER TAKE-OFF (PTO) - CHAPTER 3
31-14
11. Place the friction lining and pressure plate back
on to the assembly. Align the bolt holes, and
insert the bolts.
86065290
32
12. Place the adjustment band back on.
86065271
33
13. Insert the Belleville spring. Place the nuts on the
bolts, and finger tighten.
86065268
34
