Cisco SPA303 Administration Guide

Configuring SIP, SPCP, and NAT
Configuring SIP
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 101
4
RFC3311 Support
The Cisco SPA525G supports RFC3311, the SIP UPDATE Method.
Support for SIP NOTIFY XML-Service
The Cisco SPA300 Series and Cisco SPA500 Series IP Phones support the SIP
NOTIFY XML-Service event. On receipt of a SIP NOTIFY message with an XML-
Service event, the IP phone challenges the NOTIFY with a 401 response if the
message does not contain correct credentials. The client must be furnish the
correct credentials using MD5 digest with the SIP account password for the
corresponding line of the IP phone.
The body of the message may contain the XML event Message. For example:
<CiscoIPPhoneExecute>
<ExecuteItem Priority="0" URL="http://xmlserver.com/event.xml"/>
</CiscoIPPhoneExecute>
Authentication:
challenge = MD5( MD5(A1) ":" nonce ":" nc-value ":" cnonce ":" qop-value
":" MD5(A2) )
where A1 = username ":" realm ":" passwd
and A2 = Method ":" digest-uri
Configuring SIP
SIP settings for the Cisco SPA IP Phones are configured for the phone in general
and for individual extensions. The following sections describe SIP configuration.
Configuring SIP Parameters
To configure general SIP parameters, including enabling CTI:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the SIP tab.

Cisco SPA303 Specifications

General

Display	Monochrome LCD
Lines	3
Speakerphone	Yes
Headset Jack	Yes (2.5 mm)
Handset	Yes
Ethernet Ports	2 x 10/100 Mbps
Protocol	SIP
Power	Power over Ethernet (PoE) or AC adapter
Audio Codec Support	G.711, G.729
QoS	802.1p/q
