Customizing Cisco SPA and Wireless IP Phones
Configuring Phone Information and Display Settings
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 49
3
• Use the + character to add spaces for formatting. For example, you can add
multiple + characters before and after the text to center it.
STEP 4 In the Logo Type field, select Tex t L o g o .
STEP 5 Click Submit All Changes. The phone reboots.
Changing the Display Background (Cisco SPA300 Series and
Cisco SPA500 Series)
You can use a picture to customize the background on your IP phone LCD displays.
Phone models and acceptable image file types are:
• Cisco SPA303 and Cisco SPA50XG: Bitmap format, 1 bit-per-pixel color,
size 128 x 48 pixels.
• Cisco SPA525G/525G2: Either .jpg format (recommended) or bitmap (1, 2, 4,
8, or 24 bits-per-pixel). Recommended image size is 320 x 240 pixels. Other
image sizes are scaled to fit, which can cause distortion.
NOTE The phone does not reboot after you change the background image URL.
Cisco SPA303 and Cisco SPA50XG:
NOTE A background image is displayed while the phone is running; a logo is only
displayed during the phone's boot sequence.
STEP 1 Copy the image to a TFTP or HTTP server that is accessible from the phone.
STEP 2 Log in to the configuration utility.
STEP 3 Click Admin Login and advanced.
STEP 4 Click the Phone tab.
STEP 5 In the Select Background Picture field, select BMP Picture.
STEP 6 Enter the URL of the image file you want in the
BMP Picture Download URL
field.
The URL must include the TFTP/HTTP server name (or IP address), directory, and
filename, for example:
tftp://myserver.mydomain.com/images/downloadablepicture.bmp
or
http://myserver.mydomain.com/images/downloadablepicture.bmp
