Configuring Lines and Extensions
Configuring Lines
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 34
2
NOTE The Cisco SPA300 Series and Cisco SPA500 Series IP Phones support the “private
hold” feature for MetaSwitch and BroadSoft. Users who have a shared line can
press the “PrivHold” softkey, and the call can only be resumed by the user who
placed the call on hold.
Each station with an SLA can be configured independently. Although the account
information is usually the same for all of the stations, settings such as the dial plan
or the preferred codec can vary.
Configuring a Line
NOTE This section does not apply to the WIP310.
To configure a phone line:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 Under each line key for the phone, configure the following:
• Extension—Assign an extension to the line key. Defaults to 1. Generally you
should reserve EXT 1 on the client station as the primary and private
extension of the designated user. Configure shared extensions on EXTs 2
through 6 (depending on phone model).
•
Short Name
—Enter a short name or number to display on the LCD for the line
key.
•
Share Call Appearance
—Select shared if you want the line key to share
incoming call appearances with other phones. See
Configuring Shared Line
Appearance, page 35
. If you select private, the call appearance is private and
not shared with any other phone. Defaults to private.
• Extended Function—See Assigning Busy Lamp Field, Call Pickup, and Speed
Dial Functions to Unused Lines on a Cisco SPA300 Series or Cisco SPA500
Series IP Phone, page 36
.
NOTE The number of line keys displayed depends on the type of phone.
STEP 5 Click Submit All Changes.
