Cisco SPA303 Administration Guide

Customizing Cisco SPA and Wireless IP Phones
Configuring BroadSoft Settings (Cisco SPA300 Series and Cisco SPA500 Series)
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 90
3
To configure the BroadSoft Directory service:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 Under Broadsoft Settings, configure the following:
• Directory Enable: Set to yes.
• XSI Host Server: Enter the name of the server; for example,
xsp.xdp.broadsoft.com.
• Directory Name: Name of the directory. Displays on the user’s phone as a
directory choice (for example, “John’s Personal Directory”).
• Directory Type: Select the type of BroadSoft directory:
- Enterprise (default): Allows users to search on last name, first name, user
or group ID, phone number, extension, department, or email address.
- Group: Allows users to search on last name, first name, user ID, phone
number, extension, department, or email address.
- Personal: Allows users to search on last name, first name, or telephone
number.
• Directory UserID: BroadSoft User ID of the phone user; for example,
johndoe@xdp.broadsoft.com.
• Directory Password: Alphanumeric password associated with the User ID.
STEP 5 Click Submit All Changes.
Configuring Synchronization of Do Not Disturb and Call
Forward
Enabling synchronization of Do Not Disturb and Call Forward allows the phone to
synchronize with the call server (for example, the BroadSoft server) so that if Do
Not Disturb or Call Forwarding settings are changed on the phone, changes are
also made on the server; if changes are made on the server, they are propagated
to the phone.
This feature is disabled by default.

Cisco SPA303 Specifications

General

Display	Monochrome LCD
Lines	3
Speakerphone	Yes
Headset Jack	Yes (2.5 mm)
Handset	Yes
Ethernet Ports	2 x 10/100 Mbps
Protocol	SIP
Power	Power over Ethernet (PoE) or AC adapter
Audio Codec Support	G.711, G.729
QoS	802.1p/q
