Configuring Security, Quality, and Network Features
Configuring VLAN Settings for IP Phones
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 154
5
Configuring the VLAN Settings
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the System tab.
STEP 4 Under VLAN Settings, enter the following parameters:
Parameter Description
Enable VLAN Choose Yes to enable VLAN. Choose no to
disable.
VLAN ID If you use a VLAN without CDP (VLAN enabled
and CDP disabled), enter a
VLAN ID
for the IP
phone. Note that only voice packets are tagged
with the VLAN ID. Do not use 1 for the VLAN ID.
PC Port VLAN Highest Priority Choose No Limit, or 0-7 (default 0). The highest
priority is 7. The priority applied to all frames,
tagged and untagged. The phone modifies the
frame priority only if the incoming frame priority
is higher than this value.
Enable PC Port VLAN Tagging Enables VLAN and priority tagging on the phone
data port (802.1p/q). This feature facilities
tagging of the VLAN ID (802.1Q) and priority bits
(802.1p) of the traffic coming from the PC port of
the IP phone.
Defaults to No. Choose Ye s to enable the
tagging algorithm.
PC Port VLAN ID 0-4095 (default 0). Value of the VLAN ID. The
phone tags all the untagged frames coming from
the PC (it will not tag frames with an existing
tag).
Enable CDP Enable CDP only if you are using a switch that
has Cisco Discovery Protocol. CDP is
negotiation based and determines which VLAN
the IP phone resides in.
