Customizing Cisco SPA and Wireless IP Phones
Customizing Phone Softkeys
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 67
3
Programmable Softkeys
The Cisco SPA300 Series and Cisco SPA500 Series IP Phones provide six
programmable softkeys (fields PSK 1 through PSK 6). These keys can be defined
by either a speed dial script or an XML service script.
To configure programmable softkeys:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 (Cisco SPA525G/525G2 only) Under Programmable Softkey Enable, choose yes.
To configure a speed dial script, enter the following in the PSK field:
fnc=sd;ext=
extensionname
@$PROXY;vid=
outboundextnum
;nme=
name
where
fnc
is the function of the key (speed dial), ext (
extensionname
) is the
extension being dialed,
vid
is the extension on the calling phone from which the
outbound call is sent, and
name
is the name of the speed dial being configured.
Vertical service activation codes (* codes) are supported in speed dial
configurations.
NOTE The
name
field displays on the softkey on the phone display screen. Cisco
recommends a maximum of 8 characters for a Cisco SPA30X or Cisco SPA50X
phone and 10 characters for a Cisco SPA525G/525G2 phone. If more characters
are used, the label can be truncated on the phone display.
To configure an XML script, enter the following in the PSK field:
fnc=xml;url=http://
scriptURL.xml
;nme=
scriptname
where
fnc
is the function of the key (an XML script),
scriptURL.xml
is the URL
where the script is located, and
scriptname
is the name of the script.
NOTE The
scriptname
field displays on the softkey on the phone display screen. Cisco
recommends a maximum of 8 characters for a Cisco SPA30X or Cisco 50X phone
and 10 characters for a Cisco SPA525G/525G2 phone. If more characters are used,
the label can be truncated on the phone display.
